STANDARD FEATURES:

· Single System

1. Complete Pressure Adjustment (450 – 5000 PSI

2. Complete Flow Adjustment (0 – Full GPM)

3. Pressure and Return Ports

4. Digital Pressure Gauges (.25% Accuracy)

5. Digital Supply and Return Flow Meters

(1% Accuracy)

6. Safety Over Pressure Relief Valve

7. By-Pass Dump Valve

8. Pump Flow Control Valve

9. Pump Pressure Control Valve

· Four Pumps

1. Oilgear® Pressure Compensated Pump

2. High Pressure Hand Pump (10,000 PSI)

3. Work Sink Drain Pump

4. Reservoir Kidney Loop Pump

· High Pressure Hand Pump

1. Digital Pressure Gauge (.25% Accuracy)

2. Pressure Release Valve

3. Dedicated Port

· Instrumentation - All Gauges Feature Easy

Programmability for Field Calibration

· Two Digital Flow Meters (1% Accuracy)

1. Pump Supply Flow

2. Return Flow

· Four Digital Pressure Gauges (.25% Accuracy)

1. Pump Supply Pressure (6000 PSI)

2. Hand Pump (0 – 10,000 PSI)

3. Medium Isolated Pressure Gauge

4. High Isolated Pressure Gauge

· Safety Features

1. Ergonomically Located Emergency

Stop Switch

2. Safety Over Pressure Relief Valve

3. Safety Drip Pan Completely Covers Bottom

to Ensure Clean Floors

4. All Electrical Components Installed in

NEMA 4, 12 Enclosure

5. All Gauges are Fully Enclosed in NEMA 4. 12

Enclosure with a Clear Front Safety Glass Cover

6. Operational LED Warning Indicator Lights

7. Dual Heavy Duty Floor Locks to Ensure Stability

8. Optional Safety Glass Sliding Doors for Work

Sink

· Super Clean Filtration – Industry Leading

Filtration Ensures Quality While Increasing

Aircraft Component Life

· High Efficiency, Non-Bypass

Pressure Filter (3 Micron Absolute)

· Reservoir Kidney Loop Filter (3 Micron Absolute)

· Sink Drain Filter (3 Micron Absolute)

· Reservoir Fill Pump Filter (3 Micron Absolute)

· 4-Way Directional Flow Control Valve

Manually Operated 4-Way Directional Flow

Control Valve with Complete Flow Control

· Operational Warning Lights

1. Pressure Filter Condition

LED Warning Indicator for Clogged Conditions

2. Kidney Loop Pump Filter Condition

LED Warning Indicator

3. Reservoir Low Level LED Warning Indicator

4. High Fluid Temperature LED Warning Indicator

· 2 Stand Alone Noshock? Pressure Gauges

* Suggested Ranges 0-1000 PSI and 0-6000 PSI

· Over Pressure Gauge Savers on all Gauges

· Reservoir Kidney Loop Pump

· Continuously Filters Fluid

· Continuously Cools Fluid

· Automatic Oil Temperature Control

· Panel Mounted Oil Temperature Set Point

· Digital Oil Temperature Gauge

· Additional Features

· All Welded, 14 Gauge B3 (Brushed Finish)

Stainless Steel Cabinet

· Illuminated Work Area Provided

By Overhead Sink Light

· Test Port for all Pressure Gauges

· Easy Access Exterior Fluid Sampling

Valve to Meet Quality Parameters

· Safety Drip Pan Completely Covers Bottom

· Work Sink with Perforated Metal Grating

· Heavy Duty All Welded 1/4" Think Wall

Tubing Frame with Fork Lift Brackets

· Easy Maneuvering Ensured by Two Fixed and

Two Swivel Castors with Stability Provided by

the Heavy Duty Floor Lock

· Work Sink Drain Pump with Filter (4 GPM)

· Durable Laser Engraved, Aluminum Placards

· Panel Mounted Operational Instructions

· Current Pressure Gauge and Flow Meter

Certificates of Calibration
