最大输出流量：80GPM（60Hz)

最大输出压力：5000PSI

完全独立的双液压系统

适用机型：

A-310, Airbus A-318, Airbus A-319, Airbus A-320, Airbus A-321, Airbus A-330, Airbus A-340, Airbus A-340-600, Airbus A-380, Boeing 787, Boeing 747, Boeing 767, Boeing 777, Boeing 737 400, Boeing 737 500, Boeing 737 600, Boeing 737 700, Boeing 737 800, Boeing 737 900, Dassault Falcon 900EX, Embraer ERJ 170, Embraer ERJ 190, Gulfstream G500, Gulfstream G550, Lockheed C-130

Key Features

• Stainless steel construction

• Precise digital pressure gauges

• 100% duty cycle operation

• Temperature monitoring system

Standard Features

System A

• Complete Flow Control (0-Full GPM)

• Complete Pressure Control (250 - Full GPM)

• Variable Area Flow Meter (2% Accuracy); Optional Digital Flow Meter (1% Accuracy) Available

• Test Quality Pressure Gauge (1% Accuracy); Optional Digital Pressure Gauge (.5% Accuracy) Available

Standard Features

• Independent Dual System Includes:

• Independent Dual Motors

• Independent Dual Pumps

• Independent Dual Flow Meters

• Independent Dual Pressure Gauges

• Independent Dual Flow and Pressure Control Valves

• Independent Dual By-Pass Dump Valves

• Dual Pressure Hoses (25 Ft. Long)

• Dual Return Hoses (25 Ft. Long)

• 100% Duty Cycle, Will Deliver Maximum Flow @ Maximum Pressure

• Electric Reservoir Fill Pump System

• High Efficiency Aluminum Oil Cooler with 3 Phase Electric Motor

• Stainless Steel Reservoir - Capacity 150% of Rated Maximum Flow

• All Electrical Components Installed in Liquid Proof Enclosures (NEMA 4, 12)

• Extra Capacity, Reservoir Desiccant (Water Absorbing) Breather

• Heavy Duty Frame with Fork Lift Tubes

• Standard 50 ft. (15.2 m) Electrical Input Cable

• Guaranteed No Leaks, Stainless Steel Pan, Completely Covers Bottom

• Durable Laser Engraved, Aluminum Placards

• Panel Mounted Operational Instructions

• Current Pressure Gauge and Flow Meter Certificate of Calibration

• Easy Access Exterior Fluid Sampling Valve to Meet Quality Parameters

Instrumentation

• Dual Variable Area Flow Meters (4% Accuracy)

• Optional Dual Digital Flow Meters (1% Accuracy) Available

• Dual Test Quality Pressure Gauges (1% Accuracy)

• Optional Dual Digital Pressure Gauges (.5% Accuracy) Available

• All Optional Digital Gauges Installed in Skydrol Resistant Enclosure

• Dual Scale Pyrometer / Oil Temperature Gauge (1% Accuracy)

• Optional Digital Pyrometer / Oil Temperature Gauge Available

• Hour Meter with Maintenance Reminder Warning Light

Super Clean Filtration

• Oil Polishing Nano Filtration System (.25 Micron Absolute)

• Dual, High Efficiency, Non By-Pass Pressure Filter (3 Micron Absolute)

• Dual Large Capacity Return Filter (6 Micron Absolute)

• Dual By-Pass Filter (6 Micron Absolute)

• Dual Pump Case Drain Filters (6 Micron Absolute)

System B

• Complete Flow Control (0-Full GPM)

• Complete Pressure Control (250 - Full GPM)

• Variable Area Flow Meter (2% Accuracy); Optional Digital Flow Meter (1% Accuracy) Available

• Test Quality Pressure Gauge (1% Accuracy); Optional Digital Pressure Gauge (.5% Accuracy) Available

Durable 14 Gauge Stainless Steel Cabinet Construction

• Large Hinged Rear Access Door Provides Convenient Access and Inspection

• Removable Top Panel for Ease of Access to Unit's Components

• No Exterior Paint to Fade or Chip with Usage

• Guaranteed Not to Rust

Reservoir Fill Pump System

• For Servicing Aircraft's Reservoir (4 GPM)

Operational Warning Lights

• Dual Pressure Filters Condition LED Warning Indicators for Clogged Conditions

• Dual Return Filter Condition LED Warning Indicators for Clogged Conditions

• High Fluid Temperature LED Warning Indicator

• Reservoir Low Level LED Warning Indicator

• Operational Beacon

• Nano Filter Condition LED Warning Indicators for Clogged Conditions

• Dual By-Pass Filters Condition LED Warning Indicators for Clogged Conditions

• Pump Cavitation LED Warning Indicator
