最大输出流量：60GPM

最大输出压力：4000PSI

柴油机驱动独立的双液压系统

Key Features

• Stainless steel construction

• Precise digital pressure gauges

• 100% duty cycle operation

• Temperature monitoring system

Standard Features

General Features

• Performance Assured 100% Duty Cycle

• Will Deliver Maximum Flow @ Maximum Pressure

• Dual System for Operational Checks of Aircraft with Primary and Secondary Hydraulic Systems

• Dependable Perkins Diesel Engine

• Weather Proof Cabinet with Hose Storage

• Heavy Duty Frame with Puncture Proof Tires

• Complete with Spare Components for Maintenance

Instrumentation

• Dual Variable Area Flow Meters (4% Accuracy)

• Dual Test Quality Pressure Gauges (1% Accuracy)

• Dual Scale Pyrometer / Oil Temperature Gauge (2% Accuracy)

• Test Quality Boost Pump Pressure Gauge

Functions

• Boost pump for closed loop circuit

• Open loop configuration for filling and draining of aircraft reservoir

• Dual system with dual inlets and outlets with shut-off valves

Hydraulic System

• Axial piston pump variable stroke with proportional control of flow and pressure

• Fluid Sample Port

• Pressure filter 3 micron absolute, low pressure filter 10 micron absolute with electric clogged condition indicator

• Stainless steel reservoir capacity 150% of maximum pump output (refer to model number)

• Pressure and return hoses 35 ft. long

• High volume hand pump with filter and pressure gauge for servicing aircraft's reservoir

Control Panel

• Contains all control gauges and indicators for hydraulic system

• Accessible through hinged panel in a dust and water-proof housing

• Illuminated to enable easy operation at night

• Graphic layout for ease of operation

• Protective cover for control panel

Structure

• Strong and heavy-duty chassis

• Heavy-duty frame with dip tray

• Hydraulic and electrical components completely isolated from each other

• Canopy made of steel, spray painted

• Maximum towing speed 16 km/hour, parking brake on front wheel by tow in upright position

• Tie down / lifting points

• Fork-lift pick-up points

Accessories

• Bottle samplers for laboratory check of contamination

• All models incorporate inline sensor for connection with hydraulic contamination monitoring

• One set of hydraulic pressure and return lines, 35 ft. long

• One 45 Watt swiveling spotlight

• One CO2 fire extinguisher mounted on the outside of the unit

• One tool kit for routine scheduled/unscheduled maintenance

Switches Gauges Indicators

• Analog pressure gauge 0-4000 PSI in pressure line and 0-200 PSI in return line (1% Accuracy)

• Analog readout for actual flow

• Flow setting by flow control valve

• Pressure setting by pressure relief valve

• Temperature shut down switch

• Emergency shut-down button

• Low pressure filter clogged condition indicator

• Switch for low and high level and return pressure gauge
