最大输出流量：35GPM(60Hz)

最大输出压力：5000PSI

适用机型：

Boeing 737 100, Boeing 737 200, Boeing 737 300, Boeing 737 400, Boeing 737 500, Boeing 737 600, Boeing 737 700, Boeing 737 800, Boeing 737 900, Bombardier CRJ 700, Bombardier CRJ 900, Embraer ERJ 170, Embraer ERJ 190, Gulfstream G500, Gulfstream G550

Key Features

• Stainless steel construction

• Precise digital pressure gauges

• 100% duty cycle operation

• Temperature monitoring system

Standard Features

Performance Assured 100% Duty Cycle

• Will deliver Maximum Flow @ Maximum Pressure

• Industrial Duty Lincoln Motor

• Heavy Duty Motor Starter with Over Load Protection

Super Clean Filtration

• High Efficiency, Non-Bypass Pressure Filter (1 Micron Absolute)

• Large Capacity Return Filter (3 Micron Absolute)

Operational Warning Lights

• Pressure Filter Condition LED Warning Indicator for Clogged Conditions

• High Fluid Temperature LED Warning Indicator

Standard Features

• 100% Duty Cycle, Will Deliver Maximum Flow @ Maximum Pressure

• All Welded 0.09 Aluminum Construction

• Removable Top Panel and Rear Door for Ease of Access to Unit's Components

• High Efficiency Aluminum Oil Cooler with 3 Phase Fan

• Stainless Steel Reservoir (200 Gallons)

• All Electrical Components Installed in Liquid Proof Enclosures (NEMA 4, 12)

• Safety Assured with Exterior Electrical Panel Access

• Extra Capacity, Reservoir Desiccant (Water Absorbing) Breather

• Heavy Duty All Welded Frame with Fork Lift Tubes

• Current Pressure Gauge and Flow Meter Certificate of Calibration

• Reservoir Selector Valve (To Use Either Aircraft's or Unit's Reservoir)

• Standard #16 Pressure Hoses and #32 Return Hoses (25 ft. / 7.62 m Long)

• Standard 50 ft. (15.2 m) Electrical Input Cable

• Durable Laser Engraved Aluminum Placards

• Panel Mounted Operational Instructions

• Guaranteed No Leaks, Aluminum Pan Completely Covers Bottom

• Easy Access Exterior Fluid Sampling Valve to Meet Quality Parameters

• Easy Maneuvering Ensured with 8 in. x 3 in. Castors, Two Fixed and Two Swivel with Stability Provided by the Heavy Duty Floor Lock

• Heavy Duty Stainless Steel Bracket for Hose and Electrical Input Cord Storage
